(HCA-YS5 seriesAC Leakage current sensor) HCA-YS5系列交流漏电流传感器是应用磁调制原理研制而成的一种新型电流传感器，其输出的稳定性好，初、次级之间高度绝缘，用于讯号系统、线路检测、电监测系统等交流漏电流测量。(HCA-YS5series of AC Leakage current sensorapplication of magnetic modulation principle from the development of a new type of current sensor, output stability between primary and secondary highly insulated for signaling systems, line detection, electrical monitoringAC Leakage current measurement.) 电气参数（Electrical characteristics） 型号Type HCA10 -YS5 HCA20 -YS5 HCA50 -YS5 HCA100 -YS1 HCA200 -YS5 HCA500 -YS5 Ipn 额定输入电流（AC） Rated input 10 20 50 100 200 500 mA Ipm 测量电流范围（AC） Measuring range 12 24 60 120 240 600 mA RL 负载电阻 Load resistance ≥10 KΩ Vout 输出电压（DC） Ratedoutput voltage 5 V Vo 零电压失调 Zero offset voltage ＜±30 mV Vc 电源电压 Supply voltage 24±5% V Ic 静态功耗 Current consumption ≤60 mA Iot 零点温漂 Thermal drift of Io ≤±1.0 mV/℃ F 带宽Frequency bandwidth(-3dB) 45-60 Hz εG 精度 Accuracy 1 % εL 线性度 Linearity 1 % Tr 响应时间 Response time ≤200 mS Vd 绝缘电压 Insulation voltage 2.5 KV Ta 工作温度 Ambient operating temperature -20～+70 ℃ Ts 储存温度 Ambient storage temperature -25～+85 ℃ M 重量 mass 65 g 标准tandards EN50178/IEC61010-1/UL94-Vo/ROHS 使用说明Remarks 1、应用：通讯电源、不间断电源UPS、斩波器、电化学、整流、电源监测、电焊机、变频、开关电源、电池监测、电动机监测等领域。Application: communication power supply, uninterruptible power supply UPS chopper, electrochemical, rectifier, power monitoring, welding machines, inverter, switching power supply, battery monitoring, motor monitoring fields. 2、传感器的输出幅度可根据用户需要进行适当调节。The amplitude of the output of the sensor can be appropriately adjusted according to user needs. 3、可按用户需求定制不同额定输入电流和输出电压的传感器。Custom different rated input current and the output voltage of the sensor. 4、当待测电流从传感器穿过，即可在输出端测得电流大小。（注意：错误的接线可能导致传感器损坏）When the current to be measured is across from the sensor can be measured at the output current size. (Note: incorrect wiring may cause sensor damage)
